Breezer Radar Sport

Description

Built to support a wide range of field operations.

A dependable transmission built for sustained forward progress.

A Shimano Deore Shadow Plus rear derailleur paired with a wide-range Shimano Deore 10-51T cassette delivers smooth, reliable drive across varied terrain and long routes. An alloy 36T crankset keeps cadence controlled and power predictable, resulting in a drivetrain designed to move the sport forward without interruption.

Specifications

FRAME & FORKFrame: Breezer 4130 Butted Chromoly Steel, tapered head tube 1 1/8” to 1 1/2”, 148mm rear spacing, UDH compatible, three pack mount on top of down tube and driveside seatstay, bottle mount on seat tube and bottom of down tube, bento box mount on to tube,fender and rear rack mount, flat mount disc brakeFork: Breezer 4130 Chromoly, tapered 1 1/8 to 1 1/2 steerer tube, three pack mount on each fork leg, fender mount, 15 x 110 thru axle drop out, 51mm offset, flat mount disc brake

DRIVETRAINCrankset: Alloy crank, 170mm XS-L, 175mm XL-XXL, steel narrow side chainring 34TBB: Outboard cartridge bearingRear Derailleur: Shimano Deore Shadow Plus, 12 speedRight Shifter: Shimano Deore Rapid Fire Plus, 12 speedCassette: Shimano Deore 10-51TChain: KMC x12 EPT Anti Rust

WHEELSETRims: WTB ST i30 TCS 2.0, 32H, tubeless readySpokes: Pillar, 14 gauge, buttedFront Hub: KTi, sealed cartridge bearing, Center LockRear Hub: KTi, sealed cartridge bearing, Center Lock, MicrosplineTires: WTB Nineline 29 x 2.25 TCS Light/Fast rolling 60 TPI

BRAKESBrakes: TRP HD-R803Brake Levers: TRP HD-R803Front Rotor: TRP Center Lock, 180mmRear Rotor: TRP Center Lock, 160mm

COCKPIT & CONTACT POINTSHandlebar: Alloy, 780mm width, 15mm rise, 9° backsweep, 31.8 clamp diameterGrips: WTB Burr single sided lock onStem: Alloy, 45mm reach XS-L, 55mm reach XL-XXL, 31.8mm clampHeadset: FSASaddle: WTB Solano medium, chromoly railSeatpost: 6061 aluminum 27.2 x 350mmSeatpost Clamp: Alloy, 35mm

FIT & DETAILSColor: Low Pressure (Glossy Gray)Weight: 30.4 lbs (Size Large)
